INFUSION FLUID WARMER
Compensations:
N2O & O2 (selectable)
Capnogram:
Selectable sweep speed (4.41,0.82, or 17.64mm/sec)
Ramge:
0-150 mmHg
2 mmHg (for 0 - 40 mmHg)
Accuracy:
5% of reading (for 41-70 mmHg)
8% of reading (for 71-150mmHg)
Resolution:
1 mmHg
Response Time:
28ms
Applications
Routine transfusion.
Low flow rate infusion in ICU.
Transfusion exchange High calorie infusion
Specifications
Model:- KM-BW9
Tube size:- 3.0-4.0mm
Flow Rate
2-5.3ml./min., Suitable speed of Infusion Fluid 40-80 Drop/min.
Power
Ac-220w., 60Hz, 70w
Liquid Temperature At The Enterance 15c.- 25c.
Liquid Temperature At The Exit 30c.- 41c.
Packing Dimension:- 36.5x15.5x12.5cm
Weight : 600g
![]() |
